Features:
Compliant with the standard of IEC
High Return Loss and Low Insertion Loss.
Good reliability and stability
Polishing type: PC, UPC, and APC
Various interfaces: LC, SC, ST,FC
Core of cable: 4, 6, 8, 12, 24

Application:
Telecommunication network
Testing Equipment
Local Area Network
CATV

Parameter

parameter	unit	Bundle multi-fiber connector
		SM			MM
		PC	UPC	APC	PC
Insertion Loss (Typical)	dB	<=0.3	<=0.3	<=0.3	<=0.3
Return Loss	dB	>=45	>=50	>=60	>=20
Wavelength	nm	1310, 1510			850,1310
Exchangeability	dB	<=0.2
Vibration	dB	<=0.2
Operating Temperature	oC	-40~80
Storage Temperature	oC	-40~80
Cord diameter	mm	3.0, 2.0, 0.9
Fiber Count	F	4, 6, 8, 12,24fiber
Connector Available		FC, SC, ST, LC, MU
